What is an SMT Stencil?
SMT stencil, also called PCB stencil or solder paste stencil, is a precision stainless-steel stencil used in PCB assembly. It features laser-cut apertures aligned with PCB pads to ensure accurate and consistent solder paste deposition, minimizing defects such as bridging or misalignment and enabling reliable, high-quality PCB assembly.
Professional Laser-Cut Stencil Factory
We are a factory specializing in SMT laser-cutting stencils. We make customized stencils from your Gerber/CAD files — MOQ 1 piece, global shipping, and Southeast Asia friendly with 2–3 day express delivery. Production takes only 8–12 hours. Send us your files and our engineers check them for free.
Your Files, Checked by Our Engineers
Upload your Gerber (with solder paste layer) or DXF files and our engineers review them for free — aperture design, stencil thickness and frame choice included — before production begins.
Types of SMT Stencils
Surface mount stencils can be categorized by frame and by manufacturing process.
Non-Framework Stencil
A standalone stainless-steel sheet without a frame. More flexible and space-saving, ideal for small batches and manual assembly.
Framework Stencil
The stencil is fixed in an aluminum frame. Easy to handle and position accurately, suitable for automated pick-and-place machines.
Nano-Coating
Faster solder paste release, more uniform deposits and less cleaning — ideal for BGA, QFN and other fine-pitch components.
Electropolishing
Removes micro burrs and smooths aperture walls for better solder paste release — a perfect match with nano-coating.
Step Stencil
Varying thickness across the stencil allows precise solder paste deposition for mixed-technology and high-density boards.
Manufacturing Capabilities
Industry-standard specifications for reliable, repeatable stencil quality.
| Stencil Types | Framed & Frameless |
|---|---|
| Stencil Material | 304 stainless steel |
| Laser Precision | ±10µm cutting accuracy |
| Minimum Aperture | ≥ 0.08mm |
| Cutting Technology | Precision laser cutting |
| File Formats | Gerber (with solder paste layer), DXF |
| Max Frameless Size | ≤ 650 × 580mm |
| Max Framed Size | ≤ 736 × 736mm |
| Thickness Options | 0.10 / 0.12 / 0.15 / 0.20mm |
| MOQ | 1 piece |
| Quote Time | Same-day |
| Production Time | 8–12 hours |
| Shipping | 2–3 days to Southeast Asia (DHL / FedEx) |
How to Order
No fixed price list — quotes are based on your size and quantity. Contact us and get a same-day online quote.
WhatsApp Instant Quote
Send your files or requirements via WhatsApp and get an online quote based on size and quantity — usually within hours.
Email Your Gerber
Send your Gerber (paste layer) or DXF files to our mailbox with your target date. Our engineers check the files for free.
Free Engineer Check
Not sure about thickness or frame type? Tell us your board details — we recommend the right stencil configuration before you order.
Why Choose SMT Stencil Pro
Free Engineering Check
Every Gerber/CAD file is reviewed by our engineers before production — free of charge.
Precision & Quality
±10µm laser precision with electropolished apertures for clean, burr-free printing.
Fast & SEA-Friendly
8–12 hour production and 2–3 day express delivery to Southeast Asia.
MOQ 1 Piece
One stencil or one thousand — every order is welcome.
Our Promise
100% Safe Delivery — every stencil is packed in a cardboard box with sponge protection, guaranteed to arrive safely at your address. Not satisfied with your stencil? We re-manufacture it from your Gerber files — free of charge.
Frequently Asked Questions
What files do you accept?
Gerber files with the solder paste layer, or DXF files. Our engineers check your files for free before production.
What is the minimum order?
MOQ is 1 piece — we make one stencil or one thousand.
How fast is production and delivery?
Production takes 8–12 hours. Express delivery to Southeast Asia takes 2–3 days via DHL or FedEx.
How is my stencil packed?
Each stencil is packed in a cardboard box with sponge protection to guarantee 100% safe delivery to your address.
What if I’m not satisfied with my stencil?
We re-manufacture the stencil from your Gerber files — free of charge, until you are satisfied.
Framed or frameless — which should I choose?
Frameless stencils are flexible and space-saving, ideal for small batches and manual assembly. Framed stencils are easy to handle and suited to automated pick-and-place lines. Not sure? Ask our engineers.
Ready to start? Get a same-day quote.
Send us your Gerber/CAD files on WhatsApp or by email — free engineer check, MOQ 1 piece, 8–12h production, 2–3 days to Southeast Asia.
